A-500M-5 Features & Specifications:

Low cost，high reliability
Built-in EMI filter
Protections：Over load/Short circuit
Low output ripple&noise
Forced air cooling by Built-in DC fan
Size: 205×114×50mm
Power consumption—— 5V 80A, 400W
AC input voltage range————-176~264VAC/47~63HZ
AC inrush current——————-Cold start，40A/230VAC
Input frequency——————–47-63Hz
DC adjustment range—————-±10% rated output voltage
Output over load protection———110%-150% shut off, AC recycle to re-start
Line regulation（full load）———–≤0.5%
Rise，hold up time——————-50mS，20mS at full load（typical）
Withstand voltage——————-I/P-O/P,I/P-FG:1.5KVAC, O/P-FG,0.5KVAC,1min
Storage temperature—————- -20℃~+85℃，20%~95%RH(non condensing)
Working temperature——————10~+40℃@ 100%，+60℃@ 60% load
Safety standards———————Design refer to GB4943，UL60950-1,EN60950-1
EMC standards—————— —–Design refer to GB9254，EN55022 class A
Cooling method———————– Forced air cooling by Built-in DC fan
