FEATURES:
DVI Input Interface form: DVI-I socket
Signal standard: DVI1.0
Resolution: VESA standard, PC to 1920×1080, HD to 1080p
HDMI Input Interface form: HDMI-A
Signal standard: HDMI2.0 backward compatible
Resolution: VESA standard,≤3840×2160@60Hz
DP Input Interface form ：DP
Signal standard:DP1.2backward compatible
Resolution: VESA standard,≤3840×2160@60Hz
VGA Input Interface form: DB15 socket
Signal standard: R, G, B, Hsync, Vsync: 0 to 1Vpp ± 3dB (0.7V Video + 0.3v Sync )
75 ohm black level: 300mV Sync-tip: 0V
Resolution: VESA standard,≤1920×1080p@60Hz
EXT Input DVI or SDI，Default standard DVI
AUDIO IN Input x1，3.5mm audio port
AUDIO OUT Output x1，3.5mm audio port
Network port Output 6-way network port output interface，connected to the acceptance card，total pixels 5.2 million，Widest 8000 dots, Highest 3840dots.
MONITOR Synchronous monitoring of HDMI output interface, external LCD display，1920×1080@60Hz
Square USB port (Type B) Connect to the PC, debug the parameters of the sending card and receiving card, and program upgrades through HDSet software.
Wi-Fi Support mobile phone APP for sending card, receiving card parameter debugging, program upgrade, etc.— developing
Power interface 100-240V~50/60Hz
Whole machine power <=75W
Weight <=3.6kg
Size（mm） Case size：（Length）482mm*（width）302.8mm*（hight）65.5mm
Machine case 1.5U standard industrial chassis
